Our Standard Tolerances
The tolerances shown below are achievable on most materials.Tighter tolerances may be achievable. However, this will depend on material, thickness, production method and type of tooling used. Softer materials such as rubbers and foams may exhibit a degree of concavity on cut edges.
Non-Standard Washers:
| INSIDE DIAMETER | OUTSIDE DIAMETER | ||
|---|---|---|---|
| Size | Tolerance | Size | Tolerance |
| 2.0mm - 5.9mm | -0 / +0.2mm | 3.0mm - 5.9mm | +/- 0.1mm |
| 6.0mm - 19.9mm | -0 / +0.4mm | 6.0mm - 19.9mm | +/- 0.2mm |
| 20.0mm - 50.9mm | -0 / +0.5mm | 20.0mm - 50.9mm | +/- 0.3mm |
| 51mm + | -0 / +0.8mm | 51mm + | +/- 0.4mm |
Linear Dimensions:
| SIZE | TOLERANCE |
|---|---|
| 6mm - 19.9mm | +/- 0.25mm |
| 20mm - 50.9mm | +/- 0.4mm |
| 51mm + | +/- 0.5mm |
We are able to offer fast deliveries on components made from stock materials
Simply make a call to our Sales Team on 01769 574574, email us or complete the enquiry form for further information.
